RTU5024

Product Features

Support 200 sets of numbers, each set of numbers can be set to control relays within a specified time period.
A relay output that closes when a authorized number is called in, and automatically disconnects when the set time is reached.
After controlling the relay through the authorization phone, action SMS can be sent to the user.
Between 0 and 999 seconds, the closing time of the relay can be controlled arbitrarily, where 0 indicates that the relay will open after 0.5 seconds of closing, and 999 indicates that the relay will remain closed until the authorization number is called in.
The current status of the device (relay status and GSM signal value) can be queried through SMS instructions.
You can periodically upload the current status of the device to the first user via SMS.

Use the clock on the module and send a text message to yourself every time you turn on the device to check the time.

RTU5024 usage scenarios
Technical Parameters

GSM frequency	Frequency band 850/900/1800/1900MHz
digital output	One relay output, 3A/240VAC
Working power consumption	12V input, maximum current 50mA
SIM card	Supports 3 VSIM cards
GSM antenna	50 Ω SMA antenna interface
Operating Temperature	-20~+60 °C
relative humidity	10%～ 90%
Overall dimensions	Length 130mm * Width 74mm * Height 27mm
