📡 True Remote Control, No Distance Limit
Built‑in 4G – works anywhere with cellular signal. No distance limitation.
📞 Free Call Trigger, Zero Call Cost
Authorized numbers dial the device's SIM card. The device hangs up after the first ring and executes the ON/OFF action – no call charges.
👥 3,000 Authorized Users & Time‑Based Access
Assign up to 3,000 authorized phone numbers with individual time windows. Access expires automatically outside the allowed period.
📊 Remote Status & History
● Monitor open/close status of gates, barriers, shutters, garage doors
● Check historical open/close data with timestamps via 4G network
🛠️ Flexible Configuration & Management
● Android App (available on Google Play)
● PC software via USB for programming
● TCP/IP remote server
● MQTT cloud platform support
● Easily download access history anytime, anywhere
Key Features
Technical Specifications
|
4G |
Optional: WCDMA/TDD-LTE/FDD-LTE |
|
Digital Input |
2CH NC/NO dry contact One channel fixed for access control |
|
Digital Output |
1 Relay, 3A/240VAC |
|
Siren Output |
12VDC/1A |
|
DC Power supply |
9~36VDC/2A |
|
Power consumption |
12V input Max. 50mA/Average 25mA |
|
SIM Card |
Supporting 3V SIM Card |
|
Antenna |
50 Ω SMA Antenna interface |
|
Temperature range |
-20~+60 °C |
|
Humidity range |
Relative humidity 90% |
|
Backup battery |
3.7V/900mAH |
|
Dimension |
W88mm*D78mm*H32mm |
|
Net Weight |
260g |
